HR-HB5548

Model Number:HR-HB5548
  • Overview
    The HANRUIN Shielding Box is wide frequency band supporting range from 600 to 8000 MHz,
    and can be applied to most of the current and futurewireless communication technologies such
    as WCDMA, GSM, LTE, WiMAX, GNSS, Bluetooth, and Wi-Fi. Therefore, it can be used for mobile
    device measurementusing multi-frequency bands without limitations and is ideal for mobile
    device measurement bymaintaining stable and effective shielding performance in all
    frequency bands.

    Key Features
    ▌  Easy Opening/Closing of lid(Top Opening Type)
    ▌  Higher RF Isolation
    ▌  High Performance RF Absorber lining
    ▌  Powered by AC / DC Power Filter lines
    ▌  User Defined & Interchangeable I/O Connector Panels
    ▌  Designed to test complete systems
    ▌  Fully customizable Shielded Enclosure
    ▌  Lightweight Rack Mountable or Tabletop Options
    ▌  Rugged Stainless Steel Welded Construction
    ▌  Wireless device testing
    ▌  Perfect for 802.11 – all series
    ▌  GSM、3G、4G、5G、LTE testing
    ▌  Bluetooth, GNSS, RFID, ZigBee testing


  • Shielding Box Specifications
    Isolation :
    ≧85dB@800M~8GHz

    Dimension :
    Outside : W 570 x D 530 x H 245mm
    Inside : W 550 x D 480 x H 221mm
    Weight : Approx. 38 Kg
    Box color : white
    Box material : aluminum alloy
    Surface treatment : baked paint

    Absorber Reflectivity
    Frequency / Reflectivity(dB)
    Applicable bandwidth : 800MHz~8GHz
    Shielded effectiveness of box : 800MHz~8GHz≧85dB



    I/O Option
    User Defined Input / Output Interface Filter Options :
    Ethernet - 100M、1G、10G
    USB 2.0 & 3.0
    AC / DC Power filter
    RJ11
    Audio
    AC / DC Power filter
    Air ventilation with AC or DC fan­
    Waveguide for fiber insertion
    ST Fiber connector
    RF Ports : SMA, BNC, N


    Filter specification
